The tower crane's base is generally bolted to a big concrete pad that provides very crucial support. The base is attached to a mast or a tower and stabilizes the crane which is affixed to the inside of the building's structure. Often, this attachment point is to a concrete lift or to an elevator shaft.
Generally, the mast is a triangulated lattice structure measuring 10 feet square or 0.9m2. The slewing unit is attached to the very top of the mast. The slewing unit is made of a motor and a gear which allows the crane to rotate.
Tower cranes are able to have a maximum unsupported height of 80m or 265 feet. The tower crane's maximum lifting capacity is 16,642 kilograms or 39,690 pounds with counter weights of 20 tons. Additionally, two limit switches are utilized to be able to ensure the driver does not overload the crane. There is even another safety feature called a load moment switch to ensure that the operator does not exceed the ton meter load rating. Lastly, the maximum reach of a tower crane is 70 meters or 230 feet.
There is definitely a science involved with erecting a tower crane, especially due to their extreme heights. First, the stationary structure has to be brought to the construction location by using a large tractor-trailer rig setup. Then, a mobile crane is utilized so as to assemble the equipment portion of the crane and the jib. After that, these sections are connected to the mast. The mobile crane next adds counterweights. Crawler cranes and forklifts may be a few of the other industrial machinery that is used to erect a crane.
Mast extensions are added to the crane as the building is erected. This is how the height of the crane could match the building's height. The crane crew uses what is known as a top climber or a climbing frame which fits between the top of the mast and the slewing unit. A weight is hung on the jib by the work crew in order to balance the counterweight. When complete, the slewing unit is able to detach from the top of the mast. In the top climber, hydraulic rams are utilized to adjust the slewing unit up an additional 6.1m or 20 feet. Next, the crane driver utilizes the crane to insert and bolt into position another mast section piece.
